hammer mill

Hammer Mill with Electric Motor

Hammer mill with electric motor is easy to operate and move. It enjoys many advantages like: small size, compact structure, low power consumption, low noise and long service life. It is high-quality and cost-effective.

Technical Parameter of Hammer Mill with Electric Motor

Type Power (kw) Output (kg/h) Weight (kg) Package size (mm)
TFS-158 Three phase3 200-300 75/95 620*490*620
TFS-420 Three phase 7.5 300-600 285/310 1200*1000*1220
TFS-420A Three phase 11 300-600 310/330 1200*1000*1220
TFS-500 Three phase 11 600-800 420/440 2000*900*1700
TFS-500A Three phase 15 600-800 435/460 2000*900*1700

Video of Hammer Mill with Electric Motor

Hammer Mill with Diesel Engine

Hammer mill with diesel engine is also of high quality and competitive price. The hammer mill adopts high-speed strong wind suction grinding system and dust suction device. Its blade is made of high-carbon alloy steel. It also has many advantages, like: advanced design, compact structure, high production rate, low noise, stable performance and long service life.
What’s more, this kind of hammer mill can also be equipped with electric motor as its driving engine.

Technical Parameter of Hammer Mill with Diesel Engine

Type Power (Hp) Output (kg/h) Weight (kg) Package size (mm)
TFS-420 15 300-600 355/385 1400*1000*1220
TFS-420A 22 300-600 380/400 1400*1000*1220
TFS-500 30 600-800 400/420 2000*900*1700
Hammer mill is widely used in pulverizing wooden materials into small particles.  And it is especially common to use hammer mills in pellets production. The large-scale hammer mill is also often used in conjunction with ball mills and other cement milling equipment for crushing cement raw meal and clinker. As a professional manufacturer and supplier of pellets production, our hammer mills have also been exported to many countries and won good reputations. Our hammer mills mainly consists of two different kinds: hammer mill with electric motor and hammer mill with diesel engine.
Our TFS series hammer mill is suitable for processing fodder for the fields of agriculture, stock raising, fishery and fro biomass industry to pelletize materials like: straw, corn stalk, peanut shell, weed and tree branches and twigs, etc. Moreover, all of our hammer mills can be customized according to your specific requirements.

Working Theory of Hammer Mill

After the materials above are conveyed into the crushing chamber, they will be pulverized by the swiftly rotating hammer plates. Then the smashed pieces will be tossed out of the hammer mill via centrifugal force from the rotor and suction force from the fan. Particles failing to pass through the sieve meshes will be re-pulverized again.
